Veterinary Rigid Endoscope | 150 mm
- FOB Price
US $3500.01 - 1 piece
- group name
- Veterinary Rigid Endoscope
- Min Order
- 1 piece
- brand name
- JeetVet
- model
- RAE-301
- Nearest port for product export
- Shenzhen
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, CIP, CPT, Express Delivery
- Acceptable payment methods
- T/T, L/C
- update time
- Fri, 05 Dec 2025 20:35:41 GMT
Paramtents
Image Resolution: High Definition (HD)
Purpose Animal Stomach Examination
Working Length 150 mm
Outer Diameter of the Tube 3.1 mm
Inner Diameter of the Channel 1.2 mm
Depth of Field 5 ~ 50mm
Field Angle 120°
Pixels 160,000
Packging & Delivery
- 53cm x44cm x18cm
-
Min Order1 piece
Briefing
RAE-301 portable rigid veterinary endoscope has 150 mm working length, outer diameter 3.1 mm & inner diameter 1.2 mm, corrosion-resistant and antibacterial, which is suitable for endoscopic examination, biopsy, and minimally invasive surgery of the abdominal cavity, joints, ear and nose tracts of small, avian and exotic animals.
Detailed
Introduction to RAE-301 Veterinary Rigid Endoscope
The RAE-301 rigid endoscope veterinary support connection to smart device and veterinary imaging systems for data transmission and real-time monitoring. Its rigid design ensures stable imaging during animal diagnostics and minimally invasive surgery, like animal joint repairs, abdominal biopsies, nasal tumor assessments, bladder stone removal, pleural effusion diagnosis and treatment, etc.
Main Features
High-quality optical system
Provides Full HD resolution to ensure clear endoscopic images. 120° wider observation range. The depth of field from 5 mm to 50 mm makes it adaptable to different inspection depths.
Rigid mechanical design
The insertion tube is 150 mm long and is made of medical-grade stainless steel materials that are corrosion-resistant and antibacterial.
Convenient operation
Ergonomic handheld controller. Less than 1kg. Ensures maneuverability and ease of use, reducing operator fatigue during prolonged procedures.
Portability and Efficiency
Quick and smooth diagnosis and treatment. Reduce operational difficulty and surgical time.
Detailed Image of RAE-301 Veterinary Rigid Endoscope
Ergonomic design handle
Medical stainless steel tube
Rigid Veterinary Endoscope as a whole
Veterinary Rigid Endoscope Technical Parameters
General Parameters |
Brand
|
JeetVet
|
|
|
Model
|
RAE-301
|
||
|
Purpose
|
Mainly used for endoscopic examination, biopsy, and minimally invasive surgery of the abdominal cavity, joints, ear and nose tracts of animals.
|
||
Optical Parameters | Depth of field | 5 mm - 50 mm | |
Pixels | 160,000 | ||
Mechanical Parameters | Working length | 150 mm | |
Insertion tube material | Medical grade stainless steel material, corrosion-resistant and antibacterial | ||
Operation and Control | Control method | Ergonomic design handheld controller | |
Display | Displayed by user's smart phone, tablet or computer | ||
Lighting System | Light source type | Endoscope operates without internal electric power, drawing power from the user's mobile phone. | |
Connection and Compatibility | Connection interface | Use USB cable to connect with smart phones, tablet or computer | |
Compatible devices | Support connection to smart phone, tablet, computer for data transmission and real-time monitoring | ||
Other Functions | Disinfection method | Alcohol wiping，enzymatic cleaning solution or 2% glutaraldehyde disinfection | |
Portability | Lightweight design, equipped with a portable case, convenient for carrying and use | ||
User interface | Friendly operation interface | ||
Related Videos of RAE-301 Veterinary Rigid Endoscope
Endotracheal Intubation on a Rabbit by RAE-301 Veterinary Rigid Endoscope
A professional veterinarian demonstrates the use of JeetVet rigid veterinary endoscope for performing endotracheal intubation on a rabbit. This procedure is critical for ensuring a patent airway during surgical interventions and anesthesia. RAE-301 animal rigid endoscope, renowned for its precision and reliability, allows for enhanced visualization and accuracy in placing the endotracheal tube.
Endoscopic Examination for a Bird by RAE-301 Veterinary Rigid Endoscope
A professional veterinarian demonstrates how to use the JeetVet rigid veterinary endoscope connected to the Veterinary Image Processor to examine a bird. The high-definition image allows the veterinarian to observe the internal structure of this small bird for accurate and effective diagnosis.
Veterinary Rigid Endoscope Application Scenario
Applications of the Veterinary Rigid Endoscope
The veterinary rigid endoscope is an essential tool in modern veterinary practice, providing unparalleled visual access to a variety of anatomical regions. Its rigid construction, coupled with high-resolution optics, makes it ideal for procedures requiring precise and direct visualization. The veterinary rigid endoscope is widely used in diagnostics, surgical interventions, and therapeutic procedures across a range of species.
1. Arthroscopy:
One of the primary applications of the veterinary rigid endoscope is in arthroscopy, where it is used to examine and treat conditions within the joints of animals. This minimally invasive technique allows veterinarians to diagnose joint diseases such as osteoarthritis, synovitis, and ligament injuries with greater accuracy.
2. Laparoscopy:
In laparoscopy, the veterinary rigid endoscope is used for both diagnostic and therapeutic procedures within the abdominal cavity. This includes procedures such as liver biopsies, spays (ovariohysterectomies), cryptorchidectomy, and gastrointestinal explorations.
3. Rhinoscopy and Sinusoscopy:
The rigid endoscope is also extensively utilized in rhinoscopy and sinusoscopy, providing a direct view of the nasal passages and sinuses. This application is crucial for diagnosing and treating conditions such as chronic rhinitis, nasal tumors, and foreign body obstructions.
4. Cystoscopy:
In urogenital applications, the veterinary rigid endoscope is used in cystoscopy to examine the urinary bladder and urethra. This is particularly valuable in diagnosing and treating conditions such as bladder stones, tumors, and urethral strictures.
5. Otoscopy:
The rigid endoscope is an effective tool for otoscopic examinations, particularly in cases involving chronic ear disease or the presence of foreign bodies in the ear canal. The endoscope's high-resolution imaging allows for a detailed examination of the ear structures, enabling veterinarians to diagnose conditions such as otitis externa, polyps, or tumors.
6. Thoracoscopy:
Thoracoscopy or the examination of the thoracic cavity, is another important application of the veterinary rigid endoscope. This procedure is used to diagnose and treat conditions such as pleural effusion, lung masses, and pericardial disease. The endoscope's rigid structure and high-definition imaging capabilities allow for accurate visualization and intervention within the thoracic cavity, providing a minimally invasive alternative to traditional open thoracic surgery.
